Waterproof HDMI

防水HDMIコネクタ

製品の通し番号
Waterproof HDMI






↵
No. Specifications Standard Value
Identifications HDMI Connector
Description Receptacle
Overmolded With Cable
Current Rating 0.5A
Material Contacts: Phospor Bronze
Connector Body: PBT
Shell : Brass
Temperature Range Overmolded With Cable: -20℃~ + 80℃
Receptacle: -20℃~ + 80℃
Waterproof Rating IP66,IP67,IP68(Per IEC 60529)
Contact Resistance ≦20mΩ
Insulation Resistance ≦100mΩ at DC 500V
