| No. Specifications |
Standard Value |
| Identifications |
Mini(A),Stand(B),Middle(C),Large(D),Macro(E)-Size |
| Description |
Penal Mount, Molded With Cable and Field Installable |
| Current Rating / Pin Arrangements |
Mini(A)-2A:4~6, 5A:2~3
Stand(B)-2A:10~12, 5A:2~8, 10A:2~4,5A+2A:8, 10A+5A:6
Middle(C)-2A:18, 5A:7-14, 10A:4~6, 20A:3,5A+2A:12~14, 10A+5A:6
Large(D)-2A:20~22, 5A:18, 20A:2~7
Macro(E)-5A:31 |
| Material |
Contacts: Copper Alloy, Gold Plated
Connector Body: Nylon+GF, UL Recognized |
| Temperature Range |
Cable: -20℃~ + 80℃
Connector Body: -40℃~ + 105℃ |
| Waterproof Rating |
IP66,IP67,IP68(Per IEC 60529) |
| Contact Resistance |
≦10mΩ |
| Insulation Resistance |
≦100mΩ at DC ≦150V |
| Durability |
1000Plug / Unplug Cycles Minimun |
| Breakdown Vlotage |
≧AC 1000V / 1Minute, ≧500V / 1Minute (1.5~5) |
| Corrosion |
48 Hours Salt Spray Contact |
|
